KEY FEATURES
- 1/ 2 HP, 115 Volt, single-phase, 2-wire
- Superior draw-down capability to 4-1/2” (114mm) vs. 13-1/2” (343mm) on a standard NEMA 4”
- 25% Reduced AMP-draw 9.5 amps vs. 12.7 amps on a standard NEMA 4”
- Cooler and quieter operation – eliminates expensive “flowinducer sleeves”
- UL, CSA Listed
- Stainless steel and composite construction
- Patented and proven SignaSeal™ staging
- Exclusive STA-RITE dry-run capability
- Enclosed and self-lubricated Nylatron® shaft-bearing resists wear from abrasives
- Heavy 7/16” (12mm) positive drive 300 Series stainless steel hexagonal shaft
- Stainless steel intake screen – allows for .080” solids
- Powered by STA-RITE motors
WARRANTY
1-year limited warranty
VOLTAGE: 115 volts, 60 Hz
AMP DRAW: 9.5 amps at max load
SWITCH: None
MOTOR: Dry-wound, double ballbearing,double-seal and thermal overload protected, UL and CSA approved.
BODY: Stainless steel (300 grade)
IMPELLERS: Precision molded Acetal for perfect balance… ultra smooth for the highest performance and efficiency. Allows for .080" solids.
DIFFUSERS: Polycarbonate
BEARINGS: Nylatron®
DISCHARGE: 1-1/4" Fiberglassreinforcedthermoplastic
INTAKE SCREEN: Stainless steel
POWER CORD: 600 Volt “SJOW” jacketed 10' leads, 2-wire with ground
Please Note: When replacing a pump, the pump float must also be replaced. We will not warranty these water pumps if the float is not purchased.
